DownloadĬlick here to download the demo version of the product. There is also the option to specify a Heat Load as well as the ability to calculate any unknown two temperatures, to calculate two unknown temperatures the heat load and the flow rates must be specified. You can add your fluid physical properties and load the data to your project.Īdd your own Nusselt number correlation in two different formats through correlations database and use them during software calculations The database also included critical properties, boiling and melting points and come as separate software but easily integrated with the software.Ĭreate your own database of Plates and Components. Select from a list of 12 Nusselt number correlations.Įstimate the Physical properties of pure components for more than 1450 components the database has the ability to estimate Thermal Conductivity, Density, Heat Capacity and Viscosity.
Reynolds and Nusselt numbers calculations. Velocity through ports, Mass velocity through channel/ports calculations. Plate heat exchanger dimension calculations. Pressure drop Channel/Port/Total for Hot side and cold side Calculations. Overall Coefficient (clean / dirty) calculations Heat load required (clean or fouled) calculations. Plot temperature profiles for counter current and co-current flow Temperature and Flow rate estimation in the event of insufficient data. Import physical properties data to hot side and cold side from Microsoft Excel & from WeBBusterZ Physical properties database (included!)Įxport Results to Engineering Data sheet format (Microsoft Excel or pdf)Įxport Results summary to Microsoft excel or Print Results summary.Ībility to have multi cases in one results grid Unit converter containing 23 measurements with 200-unit conversion.įull version includes manufacturers plate database containing over 230 plates. Support S.I Units and English (U.S) Units of measurement The plate dimensions and materials can be entered, this includes the size of plate heat exchanger and chevron angle Main features The software is easy to use and have the ability to calculate unknown temperatures Please note that the software can only do the basic design calculations the mechanical design! The calculations are performed through a series of click buttons arranged in order. Gasketed Plate Heat Exchanger Design (PHex) is a software tool that is made to demonstrate the thermal analysis and calculations of Gasketed Plate Heat Exchangers.
